Applications:
Suitable for use with clean water that does not contain abrasive particles.
As a result of their relibility and the fact that they are easy to use,and suitable for use in aoolications such as domestic,gardening,irrigation and emptying tanks.
Motor:
Two-pole induction motor(n=2850 r.p.m)
Insulation Class F
ProtectionIP68
Continuous service S1
Thermal protector
Single-phase 220V/50Hz,60Hz if request
Operating conditions:
5m maximum xmmersion depth
Liquid temperature up to 35℃
Maximum ambient temperature 40℃
Pump body:Cast iron
Motor housing:Aluminum
Impeller:Aluminum
Motor shaft:Carbon steel,AlSI304 SS if request
Mechanical seal:Ceramic/Graphite
Bearings:
6201RZ/6201RZ(6202 RZ)(0.5HP)
6202RZ/6203RZ(0.75HP&1HP)
6203RZ/6203RZ(1.5HP)
Cable:7m power cable with plug
